SERIES BNC-75 RF COAXIAL CONNECTORS
|
Key performance |
Material |
|
Characteristic impedance： 75Ω
Ferquency range： 0~2GHz
Contact resistance：
Center conductor≤2.0mΩ
out conductor≤0.2mΩ
Insulation resistance： ≥5000MΩ
Insulator voltage withstanding： 1500V
Connector durability：500 |
Center contacts：
Male---brass，gold plated
Female---brassorberyllium copper，gold plated
Bodies other metal parts：
brass，nickel plated
Insulators：TFE
Crimp ferrule：brass，nickel plated
Gasket and seal rings：silicone rubber |
Applicable spec/std： GJB681A(MIL-C-39012)
 BNC-UCL/75J2.5C, BNC-UCL/75J3Y ,BNC-UCL/75J4Y,BNC-UCL/75J201C,
BNC-UCL/75J616YA
 BNC-UCL/75J4YA，BNC-UCL/75J4YB， BNC-UCL/75J4YC，BNC-UCL/75J616Y
 BNC-UCL/75JW4Y，BNC-UCL/75JW4YA
 BNC-UCL/75KY3Y  BNC-UCL/75KY3YA
BNC-UCL/75KY4YA
 BNC-UCL/75KY3YB  BNC-UCL/75KY3YC
 BNC-UCL/75KF  BNC-UCL/75KHD
 BNC-UCL/75KHD1
|
