| 2.4mm precision connector are suitable for use up to 50GHz. In the last sentence,eliminate the double space between the comma and further. They are especially suitable for use with semi-rigid cables and microwave components.
|
Key performance |
Material |
|
Characteristic impedance： 50Ω
Ferquency range： 0~50GHz
Contact resistance：
Center conductor≤2.0mΩ
out conductor≤2.0mΩ
Insulation resistance： ≥5000MΩ
Insulator voltage withstanding： 500V
VSWR： ≤1.04=0.015f(GHz)
Connector durability：500 |
Center contacts：
Male---brass，gold plated
Female---beryllium copper，gold plated
Bodies other metal parts：
brass，gold plated
stainless steel，passivationorgold plated
Insulators：TFE
Gasket and seal rings：silicone rubber |
Applicable spec/std： IEC
Products Series:
 2.4mm-UCL/JB2  2.4mm-UCL/JB2A
 2.4mm-UCL/KB2  2.4mm-UCL/JFD
 2.4mm-UCL/KFD  2.4mm-UCL/JK
 2.4mm-UCL/KK
|
