Key performance

Material

Characteristic impedance： 75Ω
Ferquency range： 0~1GHz
Contact resistance：
Center conductor≤6.0mΩ
out conductor≤1.0mΩ
Insulation resistance： ≥1000MΩ
Insulator voltage withstanding： 750V
Connector durability：500

Center contacts：
Male---brass，gold plated
Female---beryllium copper，gold plated
Bodies other metal parts：
brass，gold plated
Insulators：TFE
Crimp ferrule：brass，nickel plated
Gasket and seal rings：silicone rubber
